Titanium Tee Pipe Fittings are used to create branch connections in titanium piping systems. They help one main pipeline connect with a side branch for fluid distribution, merging, or process line expansion.
Made from pure titanium or titanium alloy, these fittings are suitable for corrosive pipeline environments such as chemical processing, seawater systems, pharmaceutical equipment, aerospace pipelines, and industrial titanium pipe networks.
Key Features
Three-way titanium pipe branch fitting
Available in equal tee and reducing tee types
Suitable for seamless or welded pipe systems
DN15 to DN600 size range available
Wall thickness from 1.5mm to 20mm
Good resistance to seawater and chemical media
Custom pipe diameter, branch size, and wall thickness available
Submit your project details quickly and let our professional team provide tailored steel structure solutions
Titanium Tee Pipe Fittings are titanium pipe fittings used to connect a branch line to a main pipeline. They are commonly used in piping systems that require fluid distribution, flow merging, bypass connection, or process line expansion.
Compared with ordinary steel pipe fittings, titanium tees are more suitable for corrosive media, seawater, chloride-containing environments, and high-demand industrial systems. They provide a reliable pipe connection solution for chemical, marine, pharmaceutical, aerospace, deep-sea, and industrial applications.
| Item | Description |
|---|---|
| Product Name | Titanium Tee Pipe Fittings |
| Material | TA1, TA2, TA3, TA4, TC4, Gr1, Gr2, Gr3, Gr4, Gr5, Gr7, Gr9 |
| Size Range | DN15 – DN600 |
| Outer Diameter | Φ18mm – Φ610mm |
| Wall Thickness | 1.5mm – 20mm |
| Standards | GB/T 12459-2017, ASTM B366 |
| Types | Equal tee, reducing tee, seamless tee, welded tee |
| Process | Hot extrusion, forming, welding, precision machining |
| Application | Chemical, aerospace, deep-sea, military, medical, and industrial pipe systems |
Clear Branch Connection Function
Titanium tee fittings are used when a main pipeline needs to connect with one side branch. They are different from titanium cross fittings, which are designed for four-direction pipeline connection.
Equal and Reducing Tee Options
Equal tees are suitable when all three pipe ends have the same diameter. Reducing tees are used when the branch pipe size is different from the main pipe.
Smooth Inner Flow Path
The internal surface can be processed to support smoother fluid movement and reduce unnecessary flow resistance inside the pipeline.
Corrosion-Resistant Titanium Material
Titanium performs well in seawater, chemical media, humid environments, and chloride-containing working conditions.
Project-Based Size Support
Pipe diameter, wall thickness, branch size, forming method, material grade, and surface finish can be adjusted according to drawings or system requirements.
Titanium Tee Pipe Fittings can be produced through titanium material preparation, forming, hot extrusion, welding if required, machining, surface treatment, dimensional inspection, and packaging.
Inspection items may include material grade, pipe diameter, wall thickness, branch alignment, surface quality, weld condition, tolerance, and appearance. Material certificates and inspection reports can be provided according to order requirements.
What are Titanium Tee Pipe Fittings used for?
They are used to create branch connections in titanium pipe systems for flow distribution, merging, or pipeline expansion.
What is the difference between equal tee and reducing tee?
An equal tee has the same diameter on all three ends, while a reducing tee has a smaller or different branch diameter.
What size range is available?
Common sizes range from DN15 to DN600, with outer diameters from Φ18mm to Φ610mm.
Can titanium tee fittings be customized?
Yes. Pipe diameter, wall thickness, branch size, material grade, and surface finish can be customized according to drawings or samples.
What information is needed for a quote?
Please provide material grade, tee type, pipe size, wall thickness, standard, quantity, and working medium.
