Titanium Plates & Sheets are used for structural parts, corrosion-resistant linings, heat exchangers, medical devices, aerospace components, and industrial equipment. They offer a strong balance of low weight, corrosion resistance, formability, and stable processing performance.
Available in pure titanium and titanium alloy grades, the plates can be supplied in different thicknesses, widths, lengths, and surface finishes according to cutting, machining, or fabrication requirements.
Key Features
Pure titanium and titanium alloy plate options
Thickness from 0.5mm to 120mm
Width from 1000mm to 2500mm
Length from 2000mm to 6000mm
Hot-rolled and cold-rolled plate options
Good corrosion resistance and lightweight strength
Cutting and size customization available
Submit your project details quickly and let our professional team provide tailored steel structure solutions
Titanium Plates & Sheets are flat titanium materials used for machining, forming, welding, lining, structural fabrication, and equipment manufacturing. They are suitable for applications that require corrosion resistance, lightweight strength, clean surface quality, and reliable dimensional stability.
Compared with ordinary metal plates, titanium plates perform better in seawater, chloride-containing media, chemical environments, and weight-sensitive structures. They are widely used in chemical equipment, aerospace parts, marine systems, medical devices, new energy equipment, and high-end manufacturing.
| Titanium Plates & Sheets | |
| Material | Chinese national standards TA1, TA2, TC4, etc.; American standards Gr1, Gr2, GR5, GR5ELI, Gr7, etc. |
| Size | Thickness: 0.5 mm – 120 mm Width: 1000 mm – 2500 mm Length: 2000 mm – 6000 mm We can customize and cut according to your drawings. |
| Implementation Standards | Chinese National Standard: GB/T 3621 American Standard: ASTM B265, AMS 4911 Medical Standard: ASTM F67 (pure titanium), ASTM F136 (TC4/Gr5 medical grade) |
| Use | Medical: Orthopedic implants, surgical instruments, medical equipment structural components Aerospace: Aircraft structural components, engine parts, skin components Chemical Corrosion Protection: Heat exchangers, reactors, electrolytic cells, corrosion-resistant linings Marine Engineering: Seawater desalination, deep-sea equipment, ship structural components New Energy: Hydrogen production equipment, photovoltaic/energy storage structural components, water electrolysis devices High-end Manufacturing: Precision instruments, automotive lightweighting, electronic equipment structural components |
| Production process | Raw materials: Sponge titanium + alloying elements Smelting: Vacuum arc remelting (VAR) furnace, casting into titanium ingots Forging/Rolling: Forging in rough form → Hot rolling into medium-thick plates → Cold rolling into thin plates Heat treatment: Annealing/solution aging to ensure mechanical properties and flatness Surface treatment: Pickling, sandblasting, wire drawing, fine grinding, brightening |
| Minimum order quantity | According to your requirements |
| Other products | Industrial pure titanium plates, titanium alloy plates, hot-rolled titanium plates, cold-rolled titanium plates, titanium coils and strips, titanium foils, and titanium composite plates.(Customizable according to your drawings and requirements） |
1. High Strength-to-Weight Ratio: Titanium Plates & Sheets are lightweight, offering a high strength-to-weight ratio, making them ideal for applications requiring both strength and low weight.
2. Excellent Corrosion Resistance: Titanium is renowned for its excellent corrosion resistance, making titanium sheets ideal for use in harsh environments.
3. Biocompatibility: Titanium sheets are biocompatible and can be used in medical implants.
4. High Melting Point: This grade of titanium has a high melting point, making it ideal for high-temperature applications.
5. Ductility: Titanium sheets are ductile, meaning they can be easily formed into various shapes and sizes.
6. Non-Magnetic: Titanium is non-magnetic, making it suitable for sensitive electronic equipment.
7. Versatile Applications: Titanium sheets can be used in a variety of applications, such as aerospace, marine, medical, and industrial applications.
We provide titanium plates, bars, wires, forgings, fittings, and custom precision components.
Yes, we support customized sizes, grades, machining, and surface treatments.
Our products are widely used in medical, industrial, aerospace, marine, and energy sectors.
Strict production control and comprehensive inspection ensure stable product quality.
Yes, sample development and small-batch production are available.
Delivery time depends on product specifications and order quantity.
Our products are exported to the United States, Germany, the United Kingdom, Australia, Japan, and many other countries.
Yes, we support OEM/ODM cooperation and welcome long-term strategic partnerships.
We use standard export packaging and can provide anti-rust, anti-shock, and customized packaging upon request.
You can contact us via email or inquiry form, and our team will quickly provide quotations and technical support.
Some medical-grade titanium materials meet relevant standards and can be used for orthopedic implant applications.
Get in touch with our team for product information, technical consultation, or customized solutions. Whether you need standard titanium products or special engineered components, we are ready to provide professional support and efficient communication.
We focus on fast response, reliable service, and long-term cooperation support, helping you move your projects forward with confidence and efficiency.
